Configuring environment
6.4 Search function on the HW platform common to both HMI systems
Expanding the user interface
Commissioning Manual, 11/2006, 6FC5397-0DP10-0BA0
6-13
Filename.bmp in archive CST.ARJ in the current directory (Bin directory)
Filename.bxx
Partial binary files, which have to be processed for reasons of compatibility with Real mode
and when starting Protected mode. These files are only searched for in the currently
selected directory.
6.4.2 Search function for COMMON.COM
Storage location of COMMON.COM
The central control file COMMON.COM must be stored in one of the following NC
directories:
● CUS: User cycles directory
● CMA: Manufacturer cycles directory
● CST: Standard cycles directory
● COM: Comment directory
The system searches through the directories for COMMON.COM in the following order. The
first file with this name is evaluated.
In HMI Advanced, the COMMON.COM control file can also be stored on the data
management path:
..\dh\cus.dir
..\dh\cma.dir
..\dh\cst.dir
..\dh\com.dir
Note
In order to activate the changes in this file, HMI Embedded WIN32 must be restarted in
conjunction with HMI Advanced (ShopMill/ShopTurn).
