Configuring the HMI system
2.2 Configuring a channel menu
HMI Advanced (IM4)
Commissioning Manual, 03/2009, 6FC5397-0DP10-3BA0
63
File CONFIG.INI
...
[T2M2N]
SK1=CH_GRP_1
SK2=CH_GRP_3
SK8=CH_GRP_15
The references CH_GRP_xx of the softkeys refer to the channel groups which must be
defined in NETNAMES.INI. This notation is binding.
This example and the conditional configuration in NETNAMES.INI defines that the channel
menu for this operating station must be assigned as follows:
3URFHVV
3URFHVV
+HDG
HQG
Figure 2-8 Horizontal softkey menu
2.2.7 Management of operating units 1:N (solution line)
Activation of the function
Configuration file mmc.ini:
[Global]
NcddeMachineName = MachineSwitch
NcddeDefaultMachineName = net:NCU_1
NcddeMachineNames = net,NCU840D
Examples of netnames.ini for 1 HMI to 3 NCUs:
[own]
owner= HMI_1
; Description of possible connections
[conn HMI_1]
conn_1= NCU_1
conn_2= NCU_2
conn_3= NCU_3
[param HMI_1]
mmc_address = 1
