Siemens SINUMERIK Commissioning Manual

Programming
2.3 Variables
Expanding the user interface
2-32 Commissioning Manual, 11/2006, 6FC5397-0DP10-0BA0
DEF Var1 = (R///,"Actual value",,"mm"//"Var1.bmp"////8,2)
Colors:
Foreground color: 8
Background color: 2
Help: none
2.3.10 Example 2: Assigning the Variable Type, Limits, Attributes, Short Text Position
properties
Example 2
Assigning the Variable Type, Limits, Attributes, Short Text Position properties
DEF Var2 = (I/0,10///wr1,al1///,,300)
Variable Type: INTEGER
Limits or toggle field entries: MIN: 0
MAX: 10
Default: none
Texts: none
Attributes:
Input mode read-only
Alignment of short text Right-justified
Help display: none
System or user variable: none
Position of short text:
Distance from left None
Distance from top None, i.e., default distance from top left
Width: 300
Position of input/output field: No data, i.e., default position
Colors: No data, i.e., default
Help: none
