Diagnostics and service
5.6 Action log
HMI Advanced (IM4)
154 Commissioning Manual, 03/2009, 6FC5397-0DP10-3BA0
PLC signal:
(initiates writing to file CRASH.COM)
• Operating mode
• Actual main program that is selected (only AUTO)
• Actual block that is active (only AUTO and MDI) and
its predecessor and successor (three block display).
• Complete program level information (all assigned
program levels with the program names including
directory)
• Actual NC block pointer (only AUTO and MDI) all
levels
• All alarms and messages that are present
• Actual position of all of the axes in the WCS
• Actual position of all axes in the MCS
• Distance to go of all axes
• Program velocity (only AUTO and MDA)
• Programmed spindle speed (only AUTO and MDA)
• Actual spindle speeds
• Override influence of the axes and spindles
• Actual tool and active tool offset
• All active G functions
• All active frames, TRAFOS... if not clearly visible from
the G function.
• All active M functions
Machine data for the action log
The machine data should be set to the following values:
General MD: Value Significance
11295 PROTOC_FILE_MEM[9]
0
1
Memory type of the log files:
= SRAM
= DRAM for solution line
18370 MM_PROTOC_NUM_FILES[9] 3 Maximum number of log files
18371 MM_PROTOC_NUM_ETPD_STD_LIST[9] 3 Number of standard ETPD data lists
Channel MD Value Significance
28300 MM_PROTOC_USER_ACTIVE[9] 1 Activating logging for a user
28302 MM_PROTOC_NUM_ETP_STD_TYP[9] 3 Number of ETP standard event types
Configuration file ACTLOG.INI
All settings of the action log are stored in file user\actlog.ini. Display MD 9012
ACTION_LOG_MODE has no meaning.
