Introduction
1.2 Booting
HMI Advanced (IM4)
Commissioning Manual, 03/2009, 6FC5397-0DP10-3BA0
11
Note
When the sorting sequence is set, if the sorting criterion is not available in the display image
of the operating area, the information is sorted in ascending order according to the column
name. The sorting sequence defined in the dialog applies to the operating areas, in which
the criterion set in the dialog appears.
System queries
You can specify whether or not an inquiry window should be displayed after certain
commands, e.g. Delete. Request acknowledgement:
● Deleting data/programs,
● Deleting directories,
● Overwriting files.
The "Representation of keys in displays..." window is opened: Here you can define whether
keys must be represented as icons or as text in HMI displays. Example: Operator panel front
in US layout
Use workpiece templates
When creating a new workpiece, you can specify here whether templates should be
transferred to the new workpiece (directory):
● Job lists
● Part programs
● Initialization programs
Trace
In the event of communication errors, a trace log for communication processes can be
recorded following an instruction to the Service department or to our hotline. The trace log is
only evaluated by Siemens.
HMI exit mode
During the commissioning phase it is often necessary to shut down the HMI-Advanced and
operating system and then reboot the PCU. To avoid powering-down and powering-up the
PCU or machine, select “Automatically reboot control on shutdown”.
See also
Configuring the prompt dialog box for the EXIT mode (Page 23)
