Tool management
6.7 Start-up of code carrier
HMI Advanced (IM4)
272 Commissioning Manual, 03/2009, 6FC5397-0DP10-3BA0
String Value Entry
wkonvert.txt
Data types for dialog variables
01
1 1 BCD T3 T3 Integer Number of cutting edges,
$P_TOOLND[tnr]
tnr=tool number
D00010E3
-10.300 4 BCD A1 A1 Double Tool OEM1,
TC_TPC1
D0000005
-5 4 BCD A2 A2 Double Tool OEM2,
TC_TPC2
0205
205 2 BCD C1 C1 Integer Subtype, $TC_DP1
B00002E3
2.3 4 BCD C5 C5 Double Geometry length1,
$TC_DP
B0000003
3 4 BCD C10 C10 Double Geometry radius1,
$TC_DP6
B000E456
0.456 4 BCD C14 C14 Double Wear length1,
$TC_DP12
2F2F
End identifier (according to TIS_EOT=0x2F2F, mmc.ini)
