Siemens SINUMERIK Commissioning Manual

Programming
2.2 Structure and elements of a dialog
Expanding the user interface
2-12 Commissioning Manual, 11/2006, 6FC5397-0DP10-0BA0
Example
//S(Start)
HS7=("Example", se1, ac7)
PRESS(HS7)
LM("Screen form1")
END_PRESS
//END
//M(Screen form1/"Example 2 : Display
graphics"/"MCP.BMP")
HS1=("new%nheader")
HS2=("")
HS3=("")
HS4=("")
HS5=("")
HS6=("")
HS7=("")
HS8=("")
VS1=("")
VS2=("")
VS3=("")
VS4=("")
VS5=("")
VS6=("")
VS7=("")
VS8=("")
PRESS(HS1)
Hd = "new header"
END_PRESS
...
//END

Siemens SINUMERIK Specifications

General

Interface	Ethernet, PROFIBUS, PROFINET, USB
Programming Languages	DIN/ISO
Display	TFT color display
Compatibility	Siemens drives and motors
Software	SINUMERIK Operate
Control Unit Type	CNC (Computer Numerical Control)
Safety Functions	Integrated safety functions up to SIL 3/PLe
