Siemens SINUMERIK Commissioning Manual

Configuring the HMI system
2.1 Processing INI files
HMI Advanced (IM4)
Commissioning Manual, 03/2009, 6FC5397-0DP10-3BA0
35
x y Explanation
Setup State=50 Entry into the Drive overview screen in Start-up with recall on exiting the level. The softkey
text is Drives/Servo .
IBSetup <root> Entry into the Settings (task 34) main screen with recall to the highest level for return.
The softkey text is
System settings .
Simulation <root> Entry into the Simulation (task 27). A modal dialog is displayed, which you can use to
select the program to be simulated. The simulation is exited by pressing Cancel. The
softkey text is Simulation .
Other interfaces in the standard applications
The following standard applications can be addressed with these:
● Parameters
● Diagnostics
● Commissioning
The following commands should be noted to the right of the equals sign in the softkey
command definition:
HSK<SoftkeyIndex>Command=Command1; Command2; ...
or
VSK<SoftkeyIndex>Command=Command1; Command2; ...
A semi-colon is used as a separator between multiple commands.
Example:
; Hide some softkeys in the horizontal softkey bar for standard operation
HSK1Command=DisableHSK(1, 3-4)
Commands
DisableHSK(< softkey list >)
The horizontal softkeys are removed from the
softkey list . Individual softkeys can be
separated by commas or specified using softkey ranges <
from > - < to >, e.g.
DisableHSK(1,3,5-7).
Note
The softkeys in the ETC bar cannot be removed.
DisableVSK(< softkey list >)
The vertical softkeys are removed from the
softkey list . Individual softkeys can be separated
by commas or specified using softkey ranges <
from > - < to >, e.g. DisableHSK(1,3,5-7).
DoVSK=<
SoftkeyIndex >
The action of the vertical softkey (1-8) is initiated.
Recall(<
status list >)
