"Custom" operating area
5.3 Defining the start dialog
Expanding the user interface
5-4 Commissioning Manual, 11/2006, 6FC5397-0DP10-0BA0
● Operating area name
HMI Advanced HMI Embedded sl
The name specified appears on the top left
of the start dialog displayed.
[HSoftkeyTexts]
HSK11 = "Custom"
The name specified appears on the top left of the
start dialog displayed.
[Task name]
Notation: Text = $80xxx
● Softkey labels
HMI Advanced HMI Embedded sl
The name entered as the operating area
name in the RE_xx.INI file is also displayed
on the configured softkey.
"xx" stands for the language code.
The text entered is displayed on the softkey
assigned. If nothing has been entered, "Custom"
will appear as the default setting.
[Softkey]
Text = $80xxx
All other elements in the "Custom" operating area, such as softkey menus or input/output
fields and the relevant functions, must be configured using the "Expand user interface" tools.
In the "Custom" application all softkeys are available as "Expand user interface" softkeys.
These softkeys are configured in the CUSTOM.COM file (like the standard version of
AEDITOR.COM included in the scope of supply) as described below.
In HMI Embedded sl, the COMMON.COM file for customer start softkeys must contain
references to CUSTOM.COM. The COMMON.COM file is supplied so that all "Custom"
operating area softkeys are linked to CUSTOM.COM.
