Programming help systems
1.2 Quick "ASCII" help
Online Help (HE1)
16 Commissioning Manual, 11/2006, 6FC5397-0DP10-0BA0
Parameters of instruction definition
Technology/topic ID/extended help/instruction text/descriptive text
Extended help
The following entries are possible in the "Extended help" parameter:
Editor help
/"PDF file name", help ID, "search string"/
Cycle help
/"PDF file name", help ID, "search string" (file name, help
screen)/
Two commas must be inserted in the "Extended help" parameter even if no entries need to
be made.
Example:
The declaration line requires the following parameters, for example:
m,t/14/"PDF filename", help ID, "search string" (file name, help
screen)/CYCLE82/drilling cycle, drilling, counterboring
The meanings of the entries for the "Extended help" parameter are as follows:
PDF file name
= File from which the descriptive text is to be displayed
Help ID
= Unique assignment to term for which the help is to be displayed
Search string
= Search string in the PDF file which is to be displayed in the help text
(File name, help screen)
= Name of file in which the help screens are stored and the name of the help screen which is
to be displayed (-> only relevant for cycle help)
CYCLE82
= Instruction text
Drilling cycle, drilling, counterboring
= Descriptive text
Call example:
m,t/14/"PGZ.PDF",1,"RTP"(drilling,CYC82)/CYCLE82/drilling cycle,
drilling, counterboring
Note
If you only want to access the PDF file, only these parameters should then appear in the
"Extended help" section.
E.g.: m,t/14/"PGZ.PDF",1,"RTP"/CYCLE82/drilling cycle, drilling, counterboring
If you only want to display the help screen, only these parameters should then appear in the
"Extended help" section.
E.g.: m,t/14/,,(drilling,CYC82)/CYCLE82/drilling cycle, drilling, counterboring
