Operating
6
6.1
Operating elements
6.1.1
Display
Introduction
Note
Repetition rate display
When operated in temperature ranges below
-10°C, the liquid crystal display of the
positioner becomes sluggish and the repetition rate display reduces
considerably.
The display has two lines. These two lines are segmented differently. Each element in the
upper line has 7 segments, whereas that in the lower line has 14 segments. Contents of the
display depend on the selected mode.
