Connection
5.2 Pneumatic
SIPART PS2 with and without HART
Operating Instructions, 10/2013, A5E00074631-11
93
5.2
Pneumatic
5.2.1
Pneumatic connections
5.2.1.1
Pneumatic connection on the standard controller
Structure
The pneumatic connections are provided on the right side of the positioner.
①
Actuating pressure Y1 for single and double-acting actuators
②
Positioner axis
③
Supply air P
Z
④
Actuating pressure Y2 for double-acting actuators
⑤
Exhaust air outlet with a sound absorber
Figure 5-23 Pneumatic connection on the standard controller
