Siemens SIPART Series - Output of system messages in the display

SIPART PS2 with and without HART
Operating Instructions, 10/2013, A5E00074631-11
201
Alarm, error, and system messages
10
10.1
Output of system messages in the display
10.1.1
System messages before initialization
Remarks about the tables:
nn
stands for variable numeric values
Error symbol
/
(slash): the texts on the left and right of the slash flash alternately
Messages before initialization (first commissioning)
Message
Line
Meaning / cause
Remedy
Up
Down
CPUStart
X
X
Message after application of electrical
auxiliary power
• Maintenance
Pnnn.n
X Potentiometer voltage of a non-initialized
positioner (P-manual mode) (actual position
value in % of the measuring range)
• Check whether the entire actuator travel
can be covered using the "+" and "-"
buttons and "P---" is never displayed
• Execute the initialization process
P---
X Measuring range was exceeded, the
potentiometer is in the inactive zone, the
transmission ratio selectors or the effective
lever arm are not adjusted as per the
actuator travel
• Switch the transmission ratio selector to
90° especially in case of part-turn
actuators
• Adjust the effective lever length of linear
actuators as per the measuring range
NOINI
X Positioner is not initialized
• Start initialization
See also
Display (Page 101)
