Technical data
12.8 Option modules
SIPART PS2 with and without HART
250 Operating Instructions, 10/2013, A5E00074631-11
12.8.6
Non-contacting position sensor
Additional modules
Without Ex protection
With Ex protection
Ex "ia"
With Ex protection
Ex "ic", "nA"
Actuating range
• Linear actuator 6DR4004-.N.20
3 to 14 mm (0.12 ... 0.55")
• Linear actuator 6DR4004-.N.30
10 ... 130 mm (0.39 ... 5.12"); up to 200 mm (7.87") on request
• Part-turn actuator
30 ... 100°
Linearity (after corrections made by
positioner)
± 1 %
Hysteresis
± 0.2%
Temperature influence (range:
rotation angle 120° or stroke
14 mm)
≤ 0.1%/10 K (≤ 0.1%/18 °F) for -20 to 90 °C (-4 to 194 °F)
≤ 0.2%/10 K (≤ 0.2%/18 °F) for -40 to -20 °C (-40 to -4 °F)
Climate class
According to DIN EN 60721-3-4
• Storage
1K5, but -40 to +90 °C (1K5, but -40 to +176 °F)
• Transport
2K4, but -40 to +90 °C (2K4, but -40 to +176 °F)
Vibration resistance
• Harmonic oscillations
(sine wave) according to
IEC 60068-2-6
3.5 mm (0.14"), 2 ... 27 Hz, 3 cycles/axis
98.1 m/s² (321.84 ft/s²), 27 ... 300 Hz, 3 cycles/axis
• Permanent shocks according to
IEC 60068-2-29
300 m/s
2
(984 ft/s
2
), 6 ms, 4000 shocks/axis
Torque for cable gland nut made of
Plastic
Metal
Stainless steel
2.5 Nm (1.8 ft lb)
4.2 Nm (3.1 ft lb)
4.2 Nm (3.1 ft lb)
Housing protection type
IP68 according to EN 60529; NEMA 4X / Encl. Type 4X
For connecting to circuits with the
following peak values
- U
i
= 5 V
I
i
= 160 mA
P
i
= 120 mW
U
i
= 5 V
Effective internal capacitance
-
C
i
= 180 nF
C
i
= 180 nF
Effective internal inductance
-
L
i
= 922 μH
L
i
= 922 μH
Certificates and approvals
CE conformity The applicable directives and standards applied with their revision levels can be
found in the EC declaration of conformity on the Internet.
