12.3 Construction
SIPART PS2 with and without HART
Operating Instructions, 10/2013, A5E00074631-11
237
12.3
Construction
Construction
How does it work?
• Range of stroke (linear actuator)
3 ... 130 mm (0.12 ... 5.12") (angle of
positioner shaft 16 ... 90°)
• Angle of rotation (part-turn actuator)
30 ... 100°
Mounting method
• On the linear actuator
Using mounting kit 6DR4004-8V and,
where necessary, an additional lever
arm 6DR4004-8L on actuators
according to IEC 60534-6-1 (NAMUR)
with rib, bars or flat face.
• On the part-turn actuator
Using mounting kit 6DR4004-8D on
actuators with mounting plane
according to VDI/VDE 3845 and
IEC 60534-6-2: The required mount
must be provided on the actuator-side.
Weight, basic device
• Glass-fiber reinforced polycarbonate housing
Approx. 0.9 kg (1.98 lb)
• Aluminum enclosure
Approx. 1.3 kg (2.86 lb)
• Stainless steel enclosure
Approx. 3.9 kg (8.6 lb)
• Flameproof aluminum enclosure
Approx. 5.2 kg (11.46 lb)
Material
• Enclosure
6DR5..0-... (Makrolon) Glass-fiber reinforced polycarbonate
(PC)
6DR5..1-... (aluminum)
GD AISi12
6DR5..2-... (stainless steel) Austenitic stainless steel mat. No.
1.4581
6DR5..5-... (aluminum, flameproof)
GK AISi12
• Pressure gauge block
Aluminum AIMgSi, anodized
Versions
• In Makrolon enclosure
Single-acting and double-acting
• In the aluminum enclosure
Single-acting
• In flameproof aluminum enclosure
Single-acting and double-acting
• In the stainless steel enclosure
Single-acting and double-acting
Torques
• Part-turn actuator fixing screws DIN 933 M6x12-A2
5 Nm (3.7 ft lb)
• Linear actuator fixing screws DIN 933 M8x16-A2
12 Nm (8.9 ft lb)
