Siemens SIPART Series User Manual

Installing/mounting
4.3 Mounting the part-turn actuator
SIPART PS2 with and without HART
40 Operating Instructions, 10/2013, A5E00074631-11
4.3
Mounting the part-turn actuator
Requirements
You require an actuator-specific VDI/VDE 3845 mount to install the positioner on a part-turn
actuator. The mount and the bolts are included in the product package of the corresponding
actuator. Ensure that the mount has a sheet metal thickness of > 4 mm and reinforcements.
Procedure
"Part-turn actuator" mounting kit 6DR4004–8D
Sr. No. *
)
Quantit
y
Name
Note
①
1 Coupling wheel Installation on positioner shaft
②
1 Carrier Installation on stump of actuator's positioner shaft
③
1 Multiple plate
Display of the actuator position, consists of scale
⑤
and pointer mark
⑥
④
8 Scale Different divisions
⑤
1 Pointer mark Reference arrow for scale
⑥
Mount Actuator-specific, VDI/VDE 3845
⑦
4 Hexagon bolt M6x12 DIN 933, torque see the chapter "Technical specifications >
Construction (Page 237)"
⑧
4 Lock washer S6
⑨
1 Socket cap screw M6x16 DIN 84
⑩
1 Washer 6.4 DIN 125
⑪
1 Hexagon socket-head
screw
Pre-installed with coupling wheel
1 Machinist's wrench
For hexagon socket-head screw
⑪
*)
The serial numbers refer to the images describing the assembly procedure for a part-turn actuator, with and without
flameproof enclosure.
