Alarm, error, and system messages
10.2 Diagnosis
SIPART PS2 with and without HART
Operating Instructions, 10/2013, A5E00074631-11
209
Overview of diagnostics values
No.
Abbreviation
Meaning
Values that can be
displayed
Unit
Reset
possible
1
STRKS
Number of strokes
0 ... 4.29E9
-
X
2
CHDIR
Number of changes of direction
0 ... 4.29E9
-
X
3
CNT
Number of fault messages
0 ... 4.29E9
-
X
4
A1CNT
Number of alarms 1
0 ... 4.29E9
-
X
5
A2CNT
Number of alarms 2
0 ... 4.29E9
-
X
6
HOURS
Operating hours
0 ... 4.29E9
Hours
-
7
WAY
Determined actuator travel
0 ... 130
mm or °
-
8
TUP
Travel time up
0 ... 1000
s
-
9
TDOWN
Travel time down
0 ... 1000
s
-
10
LEAK
Leakage
P 0.0 ... 100.0
%
-
11 PST Monitoring of the partial stroke test OFF / ###.#, fdini, notSt,
SdtSt, fdtSt, notd, Strt,
StoP
s for ###.# -
12
PRPST
time since the last partial stroke test
###, notSt, Sdtst, fdtSt
Days
-
13
NXPST
time until the next partial stroke test
OFF / ###
Days
-
14
DEVI
General control valve fault
OFF, 0.0 ... 100.0
%
-
15
ONLK
Pneumatic leakage
OFF, 0.0 ... 100.0
-
-
16
STIC
Stiction
OFF, 0.0 ... 100.0
%
-
17 ZERO Zero point displacement OFF, 0.0 .. 100.0 % -
18
OPEN
Displacement of upper end stop
OFF, 0.0 ... 100.0
%
-
19 PAVG Position average 0.0 ... 100.0 % -
20
P0
Potentiometer value of lower end stop (0%)
0.0 ... 100.0
%
-
21
P100
Potentiometer value of upper end stop (100%)
0.0 ... 100.0
%
-
22
IMPUP
impulse length up
6 ... 160
ms
-
23
IMPDN
impulse length down
6 ... 160
ms
-
24
DBUP
deadband up
0.1 ... 10.0
%
-
25
DBDN
deadband down
0.1 ... 10.0
%
-
26
SSUP
slow step zone up
0.1 ... 100.0
%
-
27
SSDN
slow step zone down
0.1 ... 100.0
%
-
28 TEMP Current temperature -50 ... 100
-58 ... 212
° C
° F
-
-
29 TMIN Minimum temperature ("min/max pointer") -50 ... 100
-58 ... 212
° C
°F
-
30 TMAX Maximum temperature ("min/max pointer") -50 ... 100
-58 ... 212
° C
° F
-
31 T1 Number of operating hours in temperature
range 1
0 ... 4.29E9 Hours -
32 T2 Number of operating hours in temperature
range 2
0 ... 4.29E9 Hours -
33 T3 Number of operating hours in temperature
range 3
0 ... 4.29E9 Hours -
