Installing/mounting
4.1 Basic safety instructions
SIPART PS2 with and without HART
Operating Instructions, 10/2013, A5E00074631-11
33
CAUTION
Please note the following before working on the control valve and when attaching the
positioner
Danger of injury.
Prior to working on the control valve, you must move the control valve into a completely
pressureless state. Proceed as follows:
Depressurize the drive chambers.
Switch off the supply air Pz.
Lock the valve in its position.
Make sure that the valve has reached the pressureless state.
If you interrupt the pneumatic auxiliary power to the positioner, the pressureless position
may only be reached after a certain waiting time.
When mounting, observe the following sequence imperatively to avoid injuries or
mechanical damage to the positioner/mounting kit:
Mount the positioner mechanically.
Connect the electrical auxiliary power supply.
Connect the pneumatic auxiliary power supply.
Commission the positioner.
WARNING
Mechanical impact energy
Protect the 6DR5...0-.G...-.... version of the positioner from mechanical impact energy
greater than 1 joule; this ensures adherence to the IP66 degree of protection.
NOTICE
Impact energy and torque
For versions 6DR5a.b-.Gc..-...., where a = 0, 2, 5, 6; b = 0, 1; c = G, N, M, P, Q, the
following is applicable:
The device must be protected against power surges of over one joule.
For versions 6DR5a.b-.Gc..-...., where a = 0, 2, 5, 6; b = 0; c = G, N, M, P, Q, the following
is applicable:
The maximum torque on the thread of the cable gland should not exceed 67 Nm.
