Connection
5.1 Electric
SIPART PS2 with and without HART
88 Operating Instructions, 10/2013, A5E00074631-11
5. Tighten the screw ① on the transparent cover ②.
6. Connect the cables of each switch to the lug of the printed circuit board in pairs. Use the
provided cable ties
③ for this purpose.
①
Screw
②
Cover
③
Cable tie
Figure 5-20 Connecting the cables
