Chapter 3: Service program PowerSys SWT 3000 Equipment Manual
Page - 8 Edition p3_3_2x 08/09 © SIEMENS AG 2008
The PowerSys menu
Figure 8: The PowerSys menu
Table 1: Functions of the PowerSys menu
Selection Function
Save Saving the device configuration in an existing file.
Save As Saving the device configuration in a new file
Program device Saving the adjustments in the device
Send Config. to Device Saving an „Off line“ configuration in the device
Print Print out of the complete device data
Print Preview Print preview. Possibility to store the preview in a file
Print Setup Modification of the printer setup
FW Package Import from firmware package for program updates
Exit Abort PowerSys program
Print Preview
With selecting <Print Preview> the program prepares a print preview which is displaying either the
equipment settings of the PowerSys program or, if opened, the event memory from an integrated
SWT 3000 in a window as shown below.
Figure 9: Display of the print preview
Print out
Saving the print preview in
the PDF or RTF format.
