SNMP and Remote Access SWT 3000 Equipment Manual
Page - 6 Edition p3_3_2x 08/09 © SIEMENS AG 2008
Equipment manual
The equipment manual is written for service and operation personnel
in the high voltage power line environment. All existing safety instructions
in the client's environment have to be observed and only trained and
instructed personnel is authorized to work with the equipment.
Installation procedure
The main steps in the installation procedure are listed below:
z Transport device or cabinet to the installation room in its packaging
z Unpack and dispose of transport packaging
z Check delivery for completeness and for mechanical damage
z Secure cabinet to the floor or wall, or install device in cabinet or rack
z Connect grounding wire
z Cable the interface modules to the protection relays
z Cable the alarm outputs
z Connect the power supply
SWT 3000 devices can be supplied as standalone devices or installed in
a cabinet together with other system components. In case of delivery in
a cabinet the entire cabling of the individually installed devices is in-
stalled at the factory up to the connection terminals on the assembly
board. In this case the connection points for the cabling can be found
in the supplied cabinet documentation.
Grounding
Caution !
The cross-sectional area of the earth wire must be equal or greater to the
cross-sectional area of any other control conductor connected to the de-
vice. The cross-section of the earth wire must be at least 2.5 qmm.
The cross section of the grounding wire and the laying of the wire must
comply with the regulations applicable for the place of installation.
