SWT 3000 Equipment Manual Chapter 3: Service program PowerSys
© SIEMENS AG 2008 Edition p3_3_2x 08/09 Page - 11
Data source <New>
After selection of the menu item <New> a menu appears for selection of the device to be param-
eterized, since the program for parameterization of the PowerLink and SWT 3000 is required:
The item SWT 3000 in this menu should be selected in the case of a Stand-alone unit. If the
SWT 3000 is integrated in the PowerLink (iSWT), PowerLink must be selected. Then the software
release has to be selected:
Figure 14: Release selection
Afterwards a file for the new database has to be defined.
Figure 15: Defining a new database
In case of changing an existing PowerLink configuration the “Clear CDB”
command should be used before programming the new configuration into
the CSP. For more details ref. to page 17.
