Pin assignment of the ALR module
Table 18: Pin assignment of the ALR
PIN Signalname PIN Signalname PIN Signalname
A1 BI1_A B1 C1
A2 B2 C2
A3 B3 C3 BI1_B
A4 B4 C4
A5 BI2_A B5 C5
A6 B6 C6
A7 B7 C7
A8 BI2_B B8 C8
A9 B9 C9
A10 B10 C10
A11 B11 C11
A12 FGND B12 FGND C12 FGND
A13 B13 C13 ALA1_OUT_L
A14 BI1_IN_L B14 C14 ALA2_OUT_L
A15 BI2_IN_L B15 C15 ALA3_OUT_L
A16 P5V B16 P5V C16 P5V
A17 GND B17 GND C17 GND
A18 P12V B18 P12V C18 P12V
A19 B19 C19
A20 B20 C20
A21 ALA1_A B21 C21
A22 B22 C22
A23 B23 C23 ALA1_B
A24 B24 C24
A25 ALA2_B B25 C25
A26 B26 C26
A27 B27 C27
A28 ALA2_A B28 C28
A29 B29 C29
A30 B30 C30 ALA3_B
A31 B31 C31
A32 ALA3_A B32 C32
