Page 124
21.5 Mains cable attachment
Attach the mains cable as follows.
Remove the screw and washer retaining the P clip
and insert the cable. Pull the cable tight and secure
with the screw and washer.
21.6 Water trap attachment
Fit the water trap as follows.
a. Remove the dust caps.
b. Screw on the Water Trap to the Air inlet. Tighten
the nut by hand only.
21.7 Miscellaneous items
Remove the protective film from the
touchscreen.
Note: The mains lead is found in the language
pack.
