25.3.5 Table of Current Alarm Condition Codes.
25.4 RS232 Connection Settings and
Testing Data Output
Connect a standard serial cable from the ventilator
to the test computer. Turn on the ventilator and
allow it to enter Ventilation Off mode. Open the
Hyper Terminal for Windows or the terminal
emulator for other operating systems, (Settings:
COM1, 19200 bps, 8 Data bits, Parity None, 1 stop
bit, Flow None or No handshake). Turn on the
ventilator, the hyper terminal should show that
comma delimited data is being sent.
Value Currently Displayed alarm condition
0 No Current Alarms
1 Oxygen Cell Disconnected
2 Calibrate Oxygen Cell
3 Oxygen Cell Exhausted
4 O2 Calibration Fail
5 High Oxygen Level
6 Low Oxygen Level
10 Monitor EEPROM Fail
11 System Fail - Monitor Isolated System
Fail
15 Pressure Sensor Drift
16 High Pressure
17 Low Pressure
18 Apnoea - pressure
19 Cycle Fail - pressure
20 Continuing Positive Pressure
25 System Fail - monitor error (comms)
26 System Fail - monitor isolated system
27 System Fail - unable to calibrate flow
ADC
28 Calibrate Flow Sensor
29 Flow Calibration Fail
30 Connect Flow Sensor
31 Faulty Flow Sensor
32 Clean Flow Sensor
40 System Fail - alarm controller fail.
45 Battery Low
46 Main Power Fail
47 Battery Fault
50 High Minute Volume
51 Low Minute Volume
52 Low Tidal Volume
53 High Patient Leak
54 Apnoea - Volume
55 Breath Not Detected
56 High Tidal Volume
60 Blocked Fresh Gas
61 Leaking Fresh Gas
62 No O2 Supply
63 No Air Supply
64 No Gas
65 Max. Pressure too low
66 Fresh Gas Solenoid Fail
67 Controller Failure - control subsys. not
responding to monitor subsys.
68 User Interface Failure
70 Controller Failure - controller has reset
unexpectedly
80 Sub Ambient Pressure
81,82 Sustained Sub Ambient pressure
84 Monitor Failure
90 Unexpected Rise in Mean P
91 Unexpected Drop in Mean P
92 Unexpected Rise in Max P
93 Unexpected Drop in Max P
94 Unexpected Rise in Min P
95 Unexpected Drop in Min P
96 Pressure change detected
100 Monitor/Display Comms Fail
101 EEProm Flow data corrupt
102 EEProm Oxygen data corrupt
103 EEProm Pressure Offset data corrupt
104 EEProm Pressure Gain data corrupt
105 EEProm Pressure Time constant Data
corrupt
