900MR088 rail clamp for MR700/MR850 heater base.

N6627/08

MR560 Dual Temperature Probe (for 700 series F&P

humidifier).

N3560

MR860 Dual Temperature Probe (for 850 F&P

humidifier).

N3860

Test Lung.

N6647

5 micron particulate filter and water trap, for air inlet.

Z0005/05

Ventilator Cart with two locking castors, basket, hose

hook and medi rail. (Shelf height 99cm).

N6670

Patient Circuit Arm.

N6627/212

Battery Fuse (10 Amp, 20 x 5mm ceramic, anti

surge).

M0799/10

User Manual for SLE4000/5000. (English)

UM131/V05/UK

Service Manual for SLE5000, Model G & G-R.

N6645/G
