A table explaining all abbreviations within this
manual can be found on page 194.
Pressure wave window with Flow
versus Pressure loop display.
Pressure wave window with
Volume versus Pressure loop
display.
Pressure wave window and Flow
wave window.
Pressure wave window and Tidal
Volume wave window.
Pressure wave window and Minute
Volume wave window.
Pressure wave window and Max
pressure against time display.
Pressure wave window and Mean
pressure against time display.
Pressure wave window and Min
pressure against time display.
Pressure wave window and O
2
%
against time display.
Pressure wave window and DCO
2
against time display.
Pressure wave window and
Resistance against time display.
Pressure wave window and
Compliance against time display.
Battery status icon, charged to
between 75% and 100%
Battery status icon, charged/dis-
charged 50% and 75%
Battery status icon, charged/dis-
charged 25% and 50%
Battery status icon, charged/dis-
charged 0% and 25%
Mains connected
Mains disconnected
