C
ONFIGURING
THE
S
WITCH
2-120
• Multicast Group Port List – Ports propagating a multicast
service; i.e., ports that belong to the indicated VLAN group.
Web – Click IGMP, IP Multicast Registration Table. Select the VLAN
ID and multicast IP address. The switch will display all the ports
that are propagating this multicast service.
CLI – This example displays all the known multicast services
supported on VLAN 1, along with the ports propagating the
corresponding services. The type field shows if this entry was
learned dynamically or was statically configured.
Console#show mac-address-table multicast vlan 1 3-152
VLAN M'cast IP addr. Member ports Type
---- --------------- ------------ -------
1 224.0.0.12 Eth1/12 USER
1 224.1.2.3 Eth1/12 IGMP
Console#
b_mgmt.book Page 120 Tuesday, July 8, 2003 5:24 PM
