VLAN C
ONFIGURATION
2-75
Displaying Current VLANs
The VLAN Current Table shows the current port members of each
VLAN and whether or not the port supports VLAN tagging. Ports
assigned to a large VLAN group that crosses several switches
should use VLAN tagging. However, if you just want to create a
small port-based VLAN for one or two switches, you can disable
tagging.
Command Attributes for Web Interface
• VLAN ID – ID of configured VLAN (1-4094, no leading zeroes).
• Up Time at Creation – Time this VLAN was created; i.e.,
System Up Time.
• Status – Shows how this VLAN was added to the switch.
- Dynamic GVRP: Automatically learned via GVRP.
- Permanent: Added as a static entry.
• Tagged Ports – Shows the tagged VLAN port members.
• Untagged Ports – Shows the untagged VLAN port members
b_mgmt.book Page 75 Tuesday, July 8, 2003 5:24 PM
