C
ONFIGURING
THE
S
WITCH
2-4
new setting. The following table summarizes the Web page
configuration buttons.
Notes: 1. To ensure proper screen refresh, be sure that Internet
Explorer 5.x is configured as follows: Under the menu
“Tools / Internet Options / General / Temporary
Internet Files / Settings,” the setting for item “Check for
newer versions of stored pages” should be “Every visit
to the page.”
2. When using Internet Explorer 5.0, you may have to
manually refresh the screen after making configuration
changes by pressing the browser’s refresh button.
Panel Display
The Web agent displays an image of the switch’s ports, indicating
whether each link is up or down. Clicking on the image of a port
opens the Port Configuration page as described on page 2-38.
Button Action
Revert Cancels specified values and restores current
values prior to pressing “Apply” or “Apply
Changes.”
Refresh Immediately updates values for the current page.
Apply Sets specified values to the system.
Apply Changes Sets specified values to the system.
b_mgmt.book Page 4 Tuesday, July 8, 2003 5:24 PM
