M
ULTICAST
C
ONFIGURATION
2-119
Web – Click IGMP, Static Multicast Router Port Configuration.
Specify the interfaces attached to a multicast router, indicate the
VLAN which will forward all the corresponding multicast traffic,
and then click Add. After you have completed adding interfaces to
the list, click Apply.
CLI – This example configures port 11 as a multicast router port
within VLAN 1.
Displaying Port Members of Multicast Services
You can display the port members associated with a specified
VLAN and multicast IP address.
Command Attribute
• VLAN ID – Selects the VLAN in which to display port members.
• Multicast IP Address – The IP address for a specific multicast
service
Console(config)#ip igmp snooping vlan 1 mrouter ethernet 1/11 3-158
Console(config)#exit
Console#show ip igmp snooping mrouter vlan 1 3-159
VLAN M'cast Router Port Type
---- ------------------ -------
1 Eth 1/11 Static
b_mgmt.book Page 119 Tuesday, July 8, 2003 5:24 PM
