VLAN C
ONFIGURATION
2-79
Adding Interfaces Based on Membership Type
Use the VLAN Static Table to modify the settings for an existing
VLAN. You can add or delete port members for a VLAN, disable or
enable VLAN tagging for any port, or prevent a port from being
automatically added to a VLAN via the GVRP protocol. (Note that
VLAN 1 is the default untagged VLAN containing all ports on the
switch, and cannot be modified via this page.)
You can use the VLAN Static Table to assign ports to the specified
VLAN group as an IEEE 802.1Q tagged port. Assign ports as tagged
if they are connected to 802.1Q VLAN-compliant devices. If the
port is connected to VLAN-unaware devices, frames will be passed
to the untagged VLAN group this port has been assigned to under
the VLAN Port Configuration page.
Command Attributes
• Port – Port identifier.
• Trunk – Trunk identifier.
• VLAN – ID of configured VLAN (1-4094, no leading zeroes).
• Name – Name of the VLAN (1 to 32 characters).
• Status – Shows if this VLAN is enabled or disabled.
- Enable: VLAN is operational.
- Disable: VLAN is suspended; i.e., does not pass packets.
b_mgmt.book Page 79 Tuesday, July 8, 2003 5:24 PM
