C
ONFIGURING
THE
S
WITCH
2-80
• Membership Type – Select VLAN membership for each
interface by marking the appropriate radio button for a port or
trunk:
- Tagged: Interface is a member of the VLAN. All packets
transmitted by the port will be tagged, that is, carry a tag and
therefore carry VLAN or CoS information.
- Untagged: Interface is a member of the VLAN. All packets
transmitted by the port will be untagged, that is, not carry a
tag and therefore not carry VLAN or CoS information. Note
that an interface must be assigned to at least one group as an
untagged port.
- Forbidden: Interface s forbidden from automatically joining
the VLAN via GVRP. For more information, see “GVRP” on
page 81.
- None: Interface is not a member of the VLAN. Packets
associated with this VLAN will not be transmitted by the
interface.
• Trunk Member – Indicates if a port is a member of a trunk.
To add a trunk to the selected VLAN, use the last table on the
VLAN Static Table page.
b_mgmt.book Page 80 Tuesday, July 8, 2003 5:24 PM
