U
PGRADING
F
IRMWARE
VIA
THE
S
ERIAL
P
ORT
B-4
For example, the following screen text shows the download
procedure for a runtime code file:
12. To set the new downloaded file as the startup file, use the [S]et
Startup File menu option.
13. When you have finished downloading code files, use the
[C]hange Baudrate menu option to change the baud rate of
the switch’s serial connection back to 9600 baud.
14. Set your PC’s terminal emulation software baud rate back to
9600 baud. Press <Enter> to reset communications with the
switch.
15. Press <Q> to quit the firmware-download mode and boot the
switch.
Select>
Xmodem Receiving Start ::
Image downloaded to buffer.
[R]untime
[D]iagnostic
[L]oader (Warning: you sure what you are doing?)
Update Image File:r
Diagnostic Image Filename : r_20019
Updating file system.
File system updated.
[Press any key to continue]
b_mgmt.book Page 4 Tuesday, July 8, 2003 5:24 PM
