129
Basic Procedure for Wipe Settings
Chapter 5 Wipes
Border: border
Soft: soft edge
Soft Border: soft border
3
Set the parameters according to the selection in step 2.
When border is selected
When soft edge is selected
When soft border is selected
4
When you selected border or soft border, select the
edge fill signal in the <Edge Fill> group.
Utility 2 Bus: signal selected on the utility 2 bus
Matte: signal from the dedicated color matte
generator
5
Depending on the operation in step 4, carry out the
following operation.
When ‘Utility 2 Bus’ is selected: Press the key
delegation button [UTIL2], turning it on, and
select the signal in the key row.
When ‘Matte’ is selected: In the same Edge/
Direction menu, press [Matte Adjust] to display
the Matte Adjust menu, then adjust the single-
color or two-color combination color matte. Select
whether to use a single-color matte or a two-color
combination in the <Edge Matte> group.
Flat Color: Adjust color 1 with the following
parameters.
When you select [Mix Color] for a two-color
combination, see the next paragraph.
Carrying out a color mix for the edge fill
matte
When you selected [Matte] for the border or soft border
edge fill, you can combine color 1 and color 2.
For the combination, you can use not only a normal wipe
generator pattern, but also the dedicated color mix pattern.
1
In the <Edge Fill> group of the Edge/Direction menu,
select [Matte], and press [Matte Adjust].
The Matte Adjust menu appears.
2
In the <Edge Matte> group, select [Mix Color],
turning it on.
3
In the <Mix Pattern> group, make one of the following
selections.
Wipe: Use the wipe pattern selected for the transition.
Pattern: Use the dedicated pattern.
4
Depending on the selection in step 3, set the following
parameters.
When Wipe is selected
When Pattern is selected
a) The patterns are the same as for a standard wipe. See “Wipe Pattern
List” (page 308).
If you selected Pattern, you can also carry out the
pattern selection by pressing the [Mix Ptn Select]
button in the Matte Adjust menu, to display the Mix
Ptn Select menu. Select any pattern appearing in the
Mix Ptn Select menu (wipe patterns 1 to 24) by
pressing the appropriate button, and you can then
adjust the following parameters.
5
If you selected Pattern in step 4, if required, the
following modifiers can be added. After selecting a
wipe mix, skip to step 6.
Knob Parameter Adjustment Setting values
1 Width Border width 0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Soft Edge softness 0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Width Border width 0.00 to 100.00
2 Inner Soft Border inner
softness
0.00 to 100.00
3 Outer Soft Border outer
softness
0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Luminance Luminance 0.00 to 100.00
2 Saturation Saturation 0.00 to 100.00
3 Hue Hue 359.99 to 0.00
Knob Parameter Adjustment Setting values
1 Size Pattern size 0.00 to 100.00
2 Soft Edge softness 0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Size Pattern size 0.00 to 100.00
2 Soft Edge softness 0.00 to 100.00
3 Pattern Pattern number 1 to 24
a)
Knob Parameter Adjustment Setting values
1 Size Pattern size 0.00 to 100.00
2 Soft Edge softness 0.00 to 100.00
To Next Page
