Basic Procedure for Wipe Settings
Chapter 5 Wipes
When turning [Position] on and setting the pattern
position
a) See page 130.
When turning [Multi] on and using replications of
the same pattern
a) See page 132.
When turning [Aspect] on and setting the aspect
ratio of the pattern
a) See page 132.
When turning [Angle] on in the <Rotation> group
and slanting the pattern
a) See page 131.
When turning [Speed] on in the <Rotation> group
and rotating the pattern at a constant rate
a) See page 131.
6 To adjust color 1, set [Color 1] on, and to adjust color
2 set [Color 2] on, then adjust the parameters.
7 To interchange color 1 and color 2, press the [Color
Invert] button, turning it on.
Setting the wipe position (Positioner)
When you turn on this function, you can move the wipe
pattern to any position.
• The parameter H Position controls the horizontal
position of the pattern.
A negative value moves the pattern to the left, and a
positive value moves the pattern to the right.
• The parameter V Position controls the vertical position
of the pattern.
A negative value moves the pattern down, and a positive
value moves the pattern up.
You can set the position independently for the main pattern
and sub pattern.
1 In the M/E-1 >Wipe menu, select HF5 ‘Main Modify.’
The Main Modify menu appears.
2 In the <Position> group, press [Position], turning it on,
and set the pattern position.
To return the pattern position to the center of the
screen
In the <Position> group, press [Center].
To move the pattern from its current position to
the center through the course of a transition
In the <Position> group, press [Auto Center], turning it on.
To set the wipe position using the trackball
You can also set the wipe position using the trackball in the
device control block.
1 In the device control block, press the [M/E1] or [P/P]
button, turning it on.
Knob Parameter Adjustment Setting values
1 Position H Horizontal
position
–200.00 to
+200.00
a)
2 Position V Vertical position –200.00 to
+200.00
a)
Knob Parameter Adjustment Setting values
1 H Multi Number of
repetitions of
pattern
horizontally
1 to 63
2 V Multi Number of
repetitions of
pattern
vertically
1 to 63
3 Invert Type Replication
layout
1 to 4
a)
Knob Parameter Adjustment Setting values
1 Aspect Aspect ratio –100.00 to
+100.00
a)
Knob Parameter Adjustment Setting values
1 Angle Angle of pattern
rotation
–100.00 to
+100.00
a)
Knob Parameter Adjustment Setting values
1 Speed Rotation rate of
pattern
–100.00 to
+100.00
a)
Knob Parameter Adjustment Setting values
1 Luminance Luminance 0.00 to 100.00
2 Saturation Saturation 0.00 to 100.00
3 Hue Hue 359.99 to 0.00
Knob Parameter Adjustment Setting values
1 Position H Horizontal
position
–200.00 to
+200.00
2 Position V Vertical position –200.00 to
+200.00
Knob Parameter Adjustment Setting values
Positioner OnPositioner Off
