137
Wipe Settings for Independent Key Transitions
Chapter 5 Wipes
2 Press one of the buttons in Table 1 above, to select the
wipe position to which the operation applies. Multiple
selection is possible.
By setting the operation mode in setup, you can also
use [K1 CB1], [K2 CB2], [K3], and [K4] to select keys
5 to 8. In this case, press [SHIFT], turning it on, then
press [K1 CB1], [K2 CB2], [K3], or [K4] to select one
of keys 5 to 8. However, it is not possible to select
more than one key.
For details of assignment for keys 5 to 8, see
“Assigning Buttons for Selection of Keys 5 to 8 in the
Setup Menu” in the Appendix (page 345).
3 Press the [POS] button, turning Position on.
4 Move the trackball or joystick, to set the wipe position.
By pressing the [X] button, turning it on, you can
restrict movement to the horizontal direction, and by
pressing the [Y] button, turning it on, you can restrict
movement to the vertical direction.
To set the wipe position by a menu operation
1 Press [Position] in the Key1 Wipe Adjust menu,
turning it on.
2 Set the following parameters.
a) See page 130.
To move the pattern from its current position to
the center through the course of a transition
Press [Auto Center] in the <Position> group, turning it on.
Rotating the wipe pattern (Rotation)
1 In the <Rotation> group of the Key1 Wipe Adjust
menu, select the rotation type.
Angle: Incline the pattern through a fixed angle.
Speed: Rotate at a speed rate.
Magnitude: Rotate the pattern through a fixed angle
during the course of the transition.
2 According to the selection in step 1, set the following
parameters.
When Angle is selected
a) See page 131.
When Speed is selected
a) See page 131.
When Magnitude is selected
a)See page 131.
Setting the wipe pattern aspect ratio
(Aspect ratio)
1 Press [Aspect] in the Key1 Wipe Adjust menu, turning
it on.
2 Set the following parameter.
Table 1: Buttons and assigned settings
Button name Setting
K1 CB1 Wipe position for independent key 1
transition
K2 CB2 Wipe position for independent key 2
transition
K3 Wipe position for independent key 3
transition
K4 Wipe position for independent key 4
transition
Table 2: Buttons assigned to functions
Button name Function
POS Toggle Position on or off.
X, Y Fix the operating direction.
CTR Return the pattern position to the
center of the screen.
Notes
Knob Parameter Adjustment Setting values
1 Position H Horizontal
position
–200.00 to
+200.00
a)
2 Position V Vertical position –200.00 to
+200.00
a)
Knob Parameter Adjustment Setting values
1 Angle Angle of pattern
rotation
–100.00 to
+100.00
a)
Knob Parameter Adjustment Setting values
1 Speed Rotation rate of
pattern
–100.00 to
+100.00
a)
Knob Parameter Adjustment Setting values
1 Angle Angle of pattern
rotation at start
of transition
–100.00 to
+100.00
a)
2 Magnitude Angle of
rotation through
course of
transition
–200.00 to
+200.00
a)
Knob Parameter Adjustment Setting values
1 Aspect Aspect ratio –100.00 to
+100.00
a)
