Applying Special Effects (Lighting and Recursive Effects)
Chapter 11 DME Operations
the light effect is not applied to the background, even if
you select BKGD or Both.
• If the setting of [Brilliancy] in the <Fill Source> group
of the Light Color Adjust menu (see page 294) is 100.00,
the light effect is not applied to the background, even if
you select BKGD or Both.
• When the global effect Combiner is set to Mix or Depth,
the light effect is not applied to the background, even if
you select BKGD or Both.
To select Surface Flat
Press [Surface Flat], turning it on.
If you have selected anything other than Flat in the
<Surface Select> group of the Spot Lighting menu, the
part corresponding only to the surface being struck by the
currently set light from the light source is shown in the
same way as if Flat had been selected.
To set the shape of the light
1 Press [Shape], turning it on.
2 Set the following parameters.
SD format
a) For more information about the shape patterns, see “Shape Patterns”
(page 354) in the Appendix.
b) 0 is a round shape, and 100 is the shape itself. Smaller values make
the pattern more rounded.
c) –1.00 is one rotation in the counterclockwise direction. +1.00 is one
rotation in the clockwise direction.
HD format
a) For more information about the shape patterns, see “Shape Patterns”
(page 354) in the Appendix.
b) 0 is a round shape, and 100 is the shape itself. Smaller values make
the pattern more rounded.
c) –1.00 is one rotation in the counterclockwise direction. +1.00 is one
rotation in the clockwise direction.
To rotate the shape pattern
1 Press [Shape Speed], turning it on.
The display on knob 5 that was visible when [Shape]
was selected changes.
2 Set the following parameter.
a) –100.00 is four rotations per second in the counterclockwise
direction, and +100.00 is four rotations per second in the clockwise
direction. 0.00 stops the rotation.
To change the light to a ring shape
If you select Parallel or Whole (see page 291) in the <Spot
Mode> group and shaping is disabled, the Ring parameter
cannot be set.
1 Press [Ring], turning it on.
2 Set the following parameter.
SD format
a) –1.00 is one rotation in the counterclockwise direction and +1.00 is
one rotation in the clockwise direction.
There is no Radius setting when Line is selected in the
<Spot Mode> group.
HD format
Knob Parameter Adjustment Setting values
1 Shape Ptn Shape pattern 1 to 2
a)
2 Size Shape size 0.00 to 6.00
3 Deform Amount of
shape
deformation
0.00 to 100.00
b)
4 Soft Softness of
shape pattern
0.00 to 100.00
5 Angle Angle of shape
pattern rotation
–8.00 to +8.00
c)
Knob Parameter Adjustment Setting values
1 Shape Ptn Shape pattern 1 to 2
a)
2 Size Shape size 0.00 to 24.00
3 Deform Amount of
shape
deformation
0.00 to 100.00
b)
4 Soft Softness of
shape pattern
0.00 to 100.00
5 Angle Angle of shape
pattern rotation
–8.00 to +8.00
c)
Knob Parameter Adjustment Setting values
5 Speed Rotation
direction and
speed
–100.00 to
+100.00
a)
Notes
Knob Parameter Adjustment Setting values
1 Offset Offset from
center
position
(radius)
–6.00 to +6.00
2 Radius Radius of
ring
0.00 to 6.00
3 Angle Rotation
angle of ring
–8.00 to +8.00
a)
Notes
Knob Parameter Adjustment Setting values
1 Offset Offset from
center position
(radius)
–24.00 to
+24.00
2 Radius Radius of ring 0.00 to 6.00
3 Angle Rotation angle
of ring
–8.00 to +8.00
a)
