562
Serial Port Settings (Serial Port Assign Menu)
Chapter 22 DCU Setup (DCU)
8
Press [Enter].
9
Repeat steps 5 to 8 as required to set the constants for
other VTRs.
Making detailed settings for a disk
recorder (Sony disk 9-pin protocol)
1
In the <DCU Select> group of the DCU >Serial Port
Assign menu, select the target for the setting (DCU1 or
DCU2).
2
Using any of the following methods, select the serial
port connected to the disk recorder for which you want
to make the settings.
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video
cursor.
• Turn the knob.
a) The range of setting values depends on the DCU port setting. (When
the MKS-2700 is connected, select 2 for the slot and a value in the
range 1 to 6 for the port.)
3
Press [Port Setting].
The DCU >Serial Port Assign >DDR SD9P Setting
menu appears.
At the top of the status area, the relevant serial port,
slot number, protocol, serial port name, SCU number,
and disk recorder type appear. In the lower part of the
status area, the response speed settings appear.
4
Using any of the following methods, specify the item
to which the response speed setting applies.
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video
cursor.
• Turn the knob.
a) 1. Maximum Open Delay: maximum time required to open a file
2. Maximum Cueup Delay: maximum time required to cue up a file
3. Play After Cueup Delay: delay time from the cued-up state to
begin playback
4. Play After Open Next Delay: delay time from the Open Next state
to begin playback
5
Turn the knob to set the disk recorder response speed.
6
Press [Set].
7
Repeat steps 4 to 6 as required to make the settings for
other items.
Making detailed settings for a disk
recorder (video disk communications
protocol)
1
In the <DCU Select> group of the DCU >Serial Port
Assign menu, select the target for the setting (DCU1 or
DCU2).
2
Using any of the following methods, select the serial
port connected to the disk recorder for which you want
to make settings.
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video
cursor.
• Turn the knob.
a) The range of setting values depends on the DCU port setting. (When
the MKS-2700 is connected, select 2 for the slot and a value in the
range 1 to 6 for the port.)
3
Press [Port Setting].
When “DDR VDCP” is selected as the protocol, the
DCU >Serial Port Assign >DDR VDCP Setting menu
appears.
BLOCK 2 1 TC READ DELAY (FRAME)
2 START DELAY (FRAME)
3 AFTER SYNC DELAY–
4 AFTER SYNC DELAY+
5MODE1
6MODE2
7 MAX PRRL SPEED
8 QUICK PVW PRRL TIME (FRAME)
Knob Parameter Adjustment Setting values
1 Port No Serial port 1 and
upwards
a)
Block Byte Setting item
Knob Parameter Adjustment Setting values
1 Item No Item selection 1 to 4
a)
Knob Parameter Adjustment Setting values
2 Setting Response speed
setting
0 to 255
Knob Parameter Adjustment Setting values
1 Port No Serial port 1 and
upwards
a)
To Next Page
