101
5 CALIBRATION
This chapter describes basic calibration procedure of the F900 system.
AUTOMATIC CALIBRATION
After tips are changed the user menu will prompt you to perform a series of automatic calibrations: Autocal Tips
Calibration, Autohome XYZ, and Auto Z Calibration.
Figure 5-1: Ca
libration Menu
START AUTO Z ZERO CALIBRATION
Start Auto Z Zero Calibration sets the model liquefier tip to the Z zero location on the build sheet.
No operator interaction is required. This is also performed automatically before each job build.
Note: Perform an Autohome XYZ before initiating automatic calibration.
Operator interaction is not required for Auto Z Stage Zero calibration.
XY and Z Tip Offset requires that the operator analyze a calibration part and
s
u
pply the system with correction values.
