BASIC SETUP
MAKING THE NETWORK CONNECTION
Processed job files are transferred to the Fortus system through your facility’s Ethernet network. An RJ45
network connector is located on the top right-hand corner at the back of the system.
Figure 3-2: Ne
twork Connection
AIR SUPPLY CONNECTION
An air supply connection is located on the top right-hand corner at the back of the system (Figure 3-2).
RJ45
Connector
Air Supply
Connector
Power Cable
Connection
