Z ZERO OFFSET
The Z Zero Offset option allows the user to make slight modifications to the Z zero factory calibration. This may
be necessary to address potential issues when changing from high temperature materials to low temperature
materials.
Selecting the Up arrow will create a + offset which moves the tip farther away from the platen. Selecting the
Do
wn arrow will create a - offset which moves the tip closer to the platen.
If adjustments are required, build the Z_Ze
ro_Verniers_XX_XXX file from the sample Job Queue. Select the
appropriate vernier for the material tip being used. Note that only T16, 0.010 slice heights are available once the
Z zero vernier is built, adjust as required.
1. Using a magnifier loop, examine both Z zero verniers to determine whether Z zero calibration is
c
orrect.
Note: Only T-16 (0.010) slice height is available. Once the Z zero vermier is built,
adjust as required.
