110
Figure 5-11: T16A Tip and Flicker
AUTOHOME XYZ
When the AutoHome icon is pressed, the system will perform the following exercise with no
operator interaction required:
1. Finds the Z home limit switch.
2
. Finds the X home limit switch.
3
. Finds the Y home limit switch.
4
. Returns to the head parked position.
Note: AutoHome is used to move away from a limit switch.
T16A Tip
Flicker
