6
Figure 1-1: Power In Disconnect Switch
3. Flip the lockout bar to the locked position. Note that the circuit breakers cannot be returned to the
O
N position when the lockout bar is in the locked position.
4. Secure the lockout bar with an external lock. The lockout bar will not stay in the locked position
w
ithout an external lock.
• Each person servicing the system should have a personal lock.
•
Never remove someone else’s lock from the lockout.
Lockout Bar
Key
