B-2 Sun Ultra 20 M2 Workstation Service Manual • January 2007
TABLE B-1 BIOS Port 80 POST Codes
Post Code Description
CFh Test CMOS R/W functionality.
C0h Early chipset initialization:
• Disable shadow RAM.
• Disable L2 cache (socket 7 or below).
• Program basic chipset registers.
C1h Detect memory:
• Auto-detection of DRAM size, type, and ECC.
• Auto-detection of L2 cache (socket 7 or below).
C3h Expand compressed BIOS code to DRAM.
C5h Call chipset hook to copy BIOS back to E000 & F000 shadow RAM.
01h Expand the Xgroup codes locating in physical address 1000:0.
02h Reserved.
03h Initial Superio_Early_Init switch.
04h Reserved.
05h 1. Blank out screen.
2. Clear CMOS error flag.
06h Reserved.
07h 1. Clear 8042 interface.
2. Initialize 8042 self-test.
08h 1. Test special keyboard controller for Winbond 977 series Super I/O
chips.
2. Enable keyboard interface.
09h Reserved.
0Ah 1. Disable PS/2 mouse interface (optional).
2. Auto-detect ports for keyboard and mouse followed by a port and
interface swap (optional).
3. Reset keyboard for Winbond 977 series Super I/O chips.
0Bh Reserved.
0Ch Reserved.
0Dh Reserved.
0Eh Test F000h segment shadow to see whether it is read/write-able or
not. If test fails, keep beeping the speaker.
0Fh Reserved.
