SV 977D User Manual - Appendixes
Table A.8. Measurement trigger parameters
Group name
#1
code
#7
code
#S
code
Code description
Triggering mode
m
0 - switched off (Off)
1 - Slope +
2 - Slope –
3 - Level +
4 - Level –
6 - Grad +
7 - External
Source of the triggering signal
s
0 - RMS
Level in SLM mode
l
x - x = level in dB (24  136)
Gradient
in SLM mode
O
x - x = gradient in dB/ms (1  100)
Level in VLM mode
n
x - x = level in dB (60  200)
Gradient
in VLM mode
k
x - x = gradient in dB/ms (1  100)
Table A.9. Logger trigger parameters
Group name
#1
code
#7
code
#S
code
Code description
Trigger Mode
XT
0 - switched off
3 - Level +
4 - Level –
Level in SLM mode
XL
CE
x - x = level in dB (24  136)
Level in VLM mode
Xy
x - x = level in dB (60  200)
Logger Pre-triggering
Number of records taken into
account before the fulfilment
of the triggering condition
XQ
x - x = number of records saved in logger
before the fulfilment of the triggering
condition; nn (0  50)
Logger Post-Triggering
Number of records taken into
account after the fulfilment of
the triggering condition
Xq
x - x = number of records saved in logger
after the fulfilment of the triggering
condition; nn (0  200)
Table A.10. Wave recording parameters
Group name
#1
code
#7
code
#S
code
Code description
Wave Recording
KC
0 - Off
1 - Continuous
2 - On Trigger
Format
IN
0 - PCM
1 - Extensible
