Page #197 background image
197
SV 977D User Manual - Appendixes
Group name
#1
code
#7
code
#S
code
Code description
Audio Sampling
FH
0 - 48kHz
1 - 24kHz
2 - 12kHz
Bits Per Sample
GO
0 - 24
1 - 16
Signal Gain
GP
x - x = signal gain level in dB
 (0  40)
Filter in SLM mode
NI
0 - HP filter
1 - Z filter
2 - A filter
3 - C filter
5 - B filter
Filter in VLM mode
NJ
0 - HP filter
Wave Name
KE
xxxxx - xxxxx up to 8 characters (permitted
characters: 0-9, A-Z and '_')
Trigger Mode
EZ
1 - Slope +
2 - Slope -
3 - Level +
4 - Level –
7 - External
10 - Integr. Period
11 - Integr. Period Split
Trigger Level in SLM mode
FD
x - x = level in dB (24  136)
Trigger Level in VLM mode
FE
x - x = level in dB (60  200)
Trigger Period
MB
0 - Log. Step
5 - 0.5 ms
1000 - 100 ms
10000 – 1 second
Recording Time
FI
0 - Inf
s - s = time in seconds (1  60)
m - m = time in minutes multiplied by 60
(160)
h - h = time in hours multiplied by 3600
(18)
Pre Trigger
FJ
n - n = time in seconds  (0  4)
Table A.11. Warnings
Group name
#1
code
#7
code
#S
code
Code description
Results Not Saved
WS
0 - Off
1 - On
Ext. Disk Free Space
WF
0 - Off
1 - On
Min Free Space
WM
x - x minimum disk free space  (1  1024)
