SV 977D User Manual - Appendixes
Group name
#1
code
#7
code
#S
code
Code description
Polarisation
Xg
0 - Positive
1 - Negative
Slope
Xh
0 - Slope +
1 - Slope -
Table A.20. STIPA parameters
Group name
#1
code
#7
code
#S
code
Code description
Result Mode
IH
18 - measurement list view
19 - frequency table
21 - area view
22 - summary view
Project Name
QR
xxxxx - xxxxx up to 8 characters (permitted
characters: 0-9, A-Z and '_')
Area Name
QS
xxxxx - xxxxx up to 8 characters (permitted
characters: 0-9, A-Z and '_')
Source Name
QX
xxxxx - xxxxx up to 8 characters (permitted
characters: 0-9, A-Z and '_')
Source Level
QZ
x - source calibration level in dB multiple by
10  (-300  300)
Table A.21. CSV export settings
Group name
#1
code
#7
code
#S
code
Code description
Summary results saved in
CSV file
CV
Reading (response from the instrument):
#7,CV,<prof1>,<prof2>,<prof3>,<spec>,<err>;
Writing: #7,CV,<prof1>,<prof2>,<prof3>,<spec>;
where
<err> - CSV file error; 0 – no error
<prof1>, <prof2>, <prof3> - profile summary
results defined as a sum of the following flags:
b0 - Time,
b1 - Lpeak,
b2 - Lmax,
b3 - Lmin,
b4 - L,
b5 - Leq,
b6 - LE,
b7 - Lden,
b8 - LEPd,
b9 - Ltm3,
b10 - LTeq,
b11 - Lnn,
b12 - LR1,
b13 - LR2,
b14 - OVL
<spec> - spectrum results defined as a
