Svantek SV 977D - Page 203

203
SV 977D User Manual - Appendixes
Group name
#1
code
#7
code
#S
code
Code description
sum of the following flags:
b0 - averaged 1/x Octave spectrum,
b1 - maximum 1/x Octave spectrum,
b2 - minimum 1/x Octave spectrum,
Note: the command accepts values in hex
format! E.g. If <prof1> = 1A (26 in decimal, sum
of bits b1, b2, b4), it means that Lpeak, Lmin and
L values from 1
st
profile are saved into CSV file.
PK0
<prof1> - profile 1 summary results
Note: the command accepts values in decimal
format!
PK1
<prof2> - profile 2 summary results
Note: the command accepts values in decimal
format!
PK2
<prof3> - profile 3 summary results
Note: the command accepts values in decimal
format!
PK3
<spec> - spectrum results
Note: the command accepts values in decimal
format!
Table A.22. Other control setting codes
Group name
#1
code
#7
code
#S
code
Code description
State of the instrument (Stop
or Start)
S
0 - STOP
1 - START
Battery state (read only)
BS
#7,BS; This function returns battery state in
percentage. If the instrument is powered from the
external power, this function return -1 or if it is
powered from the USB interface, the function
returns -2.
Battery voltage (read only)
BV
#7,BV; This function returns the battery voltage.
USB voltage (read only)
UV
#7,UV; This function returns the USB voltage.
External voltage (read only)
EV
#7,EV; This function returns the external voltage.
Statistical levels
SL
#7,SL;
This function returns all statistical levels in the
format
#7,SL,sl1,sl2,sl3,sl4,sl5,sl6,sl7,sl8,sl9,sl10;
#7,SL,sl_index,sl_level;
This function sets statistical levels where
sl_index is the statistical index, sl_level is the
statistical level and it returns the following
sequence of characters: #7,SL;
Power off (write only)
PO
This function powers off the instrument.
Last logger name (read only)
LB
#7,LB; This function returns the name of last
logger in format #7,LB,logger_name;
SD-card file system
FT
-1 - SD card not available
