SV 977D User Manual - Appendixes
Word
number
Name
Comment
21
RPM_On
rotation measurement mode:
0 – disabled
1 – enabled.
22
RPM_Pulse
Number of pulses per rotation
23
Widscreen
windscreen (only for sound measurement mode):
0 – measurement without windscreen
1 – measurement with windscreen
24
CompensationFilter
compensation filter (only for sound measurement mode):
1 – measurement with the free field compensation filter
2 – measurement with the diffuse field compensation filter
3 – measurement with the Outdoor Environment (90°) filter
4 – measurement with the Outdoor Airport (0°) filter
25
reserved
26
IEPE_Current
IEPE preamplifier currency:
0 – no current supply
1 – 1,5 mA
2 – 4,5 mA
27
SplitMode
logger file splitting mode:
0 – no splitting
-1 – split after each measurement cycle
15 – split after each full 15 minutes of real time clock
30 – split after each full 30 minutes of real time clock
60 – split after each full hour of the real time
1440 – split at defined times.
28..33
SplitTimeN
Six timestamp values of logger file splitting (only if SplitMode is 1440):
-1 – value is inactive
0..1439 – time in minutes (for example, 100 means 1:40 AM)
34
reserved
35..36
MeasureStartTimeMs
measurement start time in milliseconds
37
SplitCycles
number of split measurement files (zero means infinity) - the
parameter is important if the duration of the measurement cycle
(IntTimeSec) is set to infinity; for finite measuring cycle times this
parameter is irrelevant (see: RepCycle)
38
MicComp
microphone compensation (only for sound measurement mode):
0 – off
1 – on
39
reserved
40
TonalityStandard
Tonality standard:
0 – ISO 20065-16
1 – ISO 226-2003
2 – ISO 226-1987
41
TonalityMode
Tonality measurement mode:
0 – Auto
1 – Manual
42
MeasCount
[1…20] – numer of measuremets
43
FileLastID
last file ID in a folder
44…47
Directory
directory name
…
reserved
